Humminbird 899ci HD SI Chartplotter Fishfinder Combo

The 899ci HD SI Combo features a super bright LED backlit 7" display. This wide screen 800H x 480V, 16:9 Color provides bright, crystal-clear images for easy viewing in harsh sunlight. The Side Imaging/Down Imaging sonar with DualBeam PLUS and SwitchFire has up to 8000 watts PTP power output, GPS Chartplotting with built-in ContourXD map and Ethernet Networking capabilities. Includes a unit cover, dual card reader and Instant Access Preset buttons.

*Optional 50 kHz transducers available for extreme deepwater use

*To obtain 1000 watts, optoinal deepwater transducer required
360 Imaging

360 Imaging - We have you surrounded. 360 Imaging allows you to isolate your sweep, see 5 preset views or see all around you
Side Imaging Sonar
Welcome to Side Imaging

It’s all in the details. Gain a 180 degree side-to-side perspective on the world below the surface with remarkable Humminbird® Side Imaging®. In an instant, the ultra-thin beam scans the area up to 240 feet to the left and right of your boat location—for total coverage of up to 480 feet. The return image for each slice is then added to the images taken immediately before and after to build an incredible view of the lake bottom. You can then magnify the detail of the image with the zoom feature or mark the GPS location of promising cover or structure directly on the screen.

Side Imaging's high-frequency

beams reveal structure, cover, and contour changes with crystal clarity. The images are so real you might think it’s a camera, but it’s not, so it doesn’t matter how murky the water is.

How to Read Side Imaging

Understanding a few simple concepts will help you grasp the detailed images of Humminbird Side Imaging and make you a master of the lake or sea bottom. Compare the screenshot and diagram to help visualize how Side Imaging works. We’ve included several callouts to explain what you’re seeing. Remember, Side Imaging is a history of what you’ve already passed by.

A- Boat Location
The position of your boat in relation to the on-screen image. The on-screen image is a history of what you have passed over.
B- Water column
The dark blue area shows structure, cover and activity between the surface and lake bottom.
C- Bottom Profile
Reveals depth and terrain directly beneath the path of your boat.
D- Flat Terrain
Neutral shades of blue represent flatter terrain.
E- Descending Terrain
Dark shades of blue represent descending terrain.
F- Rising Terrain
Lighter shades of blue typically represent terrain rising from the bottom. Sometimes, very hard bottoms appear as a whiter shade.
G- Fallen Log
The shortened horizontal shadows indicate cover very close to the bottom of the lake. The angle of the shadow gives away the orientation of the log.
H- Standing Timber
Objects standing off the bottom directly below the boat will appear in the water column. Structure to the left or right of the boat will appear as a clearly defined bright shape with an adjacent, dark sonar "shadow." This shadow is not caused by light; rather it's the lack of sonar return because the object has already reflected the sonar energy. Generally, long shadows indicate the object is tall, and small shadows indicate something is short. It's important to note the shadow will often tell you more about the object than the primary sonar reflection.

Visualizing Side Imaging

Reading the image produced by Humminbird Side Imaging is easy. Simply visualize the screen folded in half down the middle (behind the boat). Then, fold the image again at the lowest point of the water column. The dark blue area provides a visual representation of the water column and lake bottom directly below your boat.

Understanding the Beam

Humminbird Side Imaging Sonar uses a razor thin beam to take a “sonar snapshot” of the area up to 240 ft. to the left and right of your location. The return image for this slice is then added to the images taken immediately before and after to build an incredibly detailed view of the lake bottom.

Bridge Pilings

Submerged bridge pilings on lake bottom.

Finding Bait

Side Imaging reveals balls of bait that you can use when targeting where fish are feeding.

Mark Waypoints

See something interesting like the sunken sailboat shown here? Save its exact GPS location as a waypoint on your Humminbird Imaging screen for easy return trips.

Zoom

Enable the zoom mode to hone in on the tiniest details. Here, we’re able to identify predators feeding on baitfish in the water column.

Split Screen

View multiple Humminbird sonar technologies at once for a complete picture. Here, we’re able to see this wreck from several angles for optimal lure/bait presentation.

Range Lines

Enable range lines to judge the distance between your boat and underwater objects. Here, we can easily see the main hull of this wreck is 27 feet from our starboard side.

Contour Mode

Use Contour Mode to remove the water column. Note how this submerged railroad track now appears as though we’re looking straight down at it from our boat.

Color Palette

Adjust color palette, sensitivity and sharpness to match conditions, enhance detail and target fish species. Changing color schemes helped shed new light on this cover.

Side Imaging Sonar -- Gain a 180° side to side perspective on the world below the surface

Down Imaging Sonar
Down Imaging Sonar -- Get a fish-eye's view of what's happening below your boat. Incredible images are created with High-frequency sound waves.

Switchfire
SwitchFire Sonar -- Take command of how your sonar returns appear with our Clear and Max Modes

DualBeam Plus Sonar
Two beams combine for great detail and a wide coverage area. Use the narrow beam for high-accuracy returns and bottom. Use the wide beam when you want a larger search area

Internal GPS
GPS antenna built into the head unit

Upgradeable Software
Up-gradable Software -- Access software updates to enhance the performance of your Humminbird unit through our My Humminbird section of the site

Dual Card Slots
Dual SD Card Slots -- Use one slot for advanced cartography and the other to save screenshots, sonar recordings and waypoints

High Definition Display
Provides bright, crystal-clear images for easy viewing in harsh sunlight

ContourXD Cartography
Contour XD is our built-in base map cartography that covers 3,000 US lakes with depth contours and many other locations without contours.

Ethernet
Rig up the ultimate fishing system. Use our 5-Port Ethernet switch to link together multiple Humminbird head units or share transducers.

HD Radar
In darkness and fog, busy channels and treacherous weather, situational awareness is the name of the game

AIS
Battle fish - not other boats. Humminbird's state of the art AIS technology takes the risk and guesswork out of navigating high-traffic channels or low-visibility seas.

NMEA
NMEA 2000 ready - Boat performance, weather or water conditions, make sense of it all with our networking solutions

I-PilotLink
i-Pilot Link is an integrated GPS Trolling System available on select Minn Kota Terrova and PowerDrive V2 motors which enable your motor and Humminbird to communicate
