Lowrance G4™ Radar Specifications:

* Range: True 32 NM (36nm display) 50% more than 3G and 2X BR24
* Closes target to Radar: 2 Meters
* Safe Distance from Dome: -0- Meters (OK to Touch)
* Warm up Time: -0- Seconds
* Operating / Standby Power: 21W dual range/2.9W
* Scanner rotation speed: 48 RPM
* Interface - radar data: Etheet
* Advanced Use modes: Offshore / Harbor

Unique 4G™ Features:

* Designed for optimal target separation, Broadband 4G Radar is the world’s first dome radar to use Beam Sharpening, which significantly improves azimuth resolution — the effective horizontal beam width of the radar signal. The result is a resolution that is equivalent to a 3.5-foot, open-array radar
* Range: Up to 50% more range and target detection ability than 3G ; 2X more than BR24
* Same proven short range performance as 3G and BR24
* Azimuth Resolution: Up to 2X better than 3G / BR24 using Target Separation Mode control – same as 3.5’ Open array
* Dual Range: Provides totally independent radar display ranges and controls - including dual MARPA with (10) Targets on each side (20 total)
  -Note: MFD model dependent High Speed Up to 48 RPM (Note: mode and MFD model dependent)
* Directional Sidelobe Reduction: Advanced signal processing allows you to see small targets better next to large targets such as ships and bridges
* InstantOn™: About 6 seconds max from cold boot start (faster than display boot time), instantaneous from standby.
  -Faster than 3G/BR24
  -Safety feature: switch the unit on and use it
  -No need to wait for 2-3 minutes or more for conventional pulse radar to warm up
  -2 minutes is a long time if you are conceed about potential collision
* Low power draw: 21 Watts operating (dual range)/2.9 watts in standby, vs. 25/30w operating and ~10/15w in standby for 2/4kW pulse radars
  -Conserves power for smaller vessels and sailboats.
  -Beneficial for complex installs on mid-size center consoles
  -20-40% Savings in operating mode vs. 2/4 kW pulse radars.
* Low electromagnetic emissions 0.165 watts (at antenna port) vs. 1 watt for a cell phone
  -Easier to install and safer to use
  -Flexible mounting options with Safe operation on smaller boats
  -Can run in anchorages and marinas
* Connectivity: Connects to range of Navico multi-function displays via Etheet
  -Same as 3G/BR24
  -Easier to install with small diameter connectors and thinner/lighter cabling

General Specifications:

* Input Power (At end of Radar Cable):
  -9-31.2 Volts DC (12 /24 Volt Systems)
  -Reverse Polarity Protections
  -Minimum Start-up Voltage 10.8 Volts
* Power Consumption: (with 10 meter cable)
  -20 watts @ 13.8 Volts DC (21 watts in Dual Range Mode)
  -Standby Mode: 2.9 Watts @ 13.8 Volts Dc
* Outside Dimensions: 11.02" High x 19.28" Diameter

Kit Includes:

* 000-10417-001  Wahoo Premium radar unit with 2 x SIM decal
* AA010212  Cable, Exteal, BB RADAR - 20m (66ft)
* AA010189  Interface Box, BB radar, N2K, RI10
* 000-0127-51  Cable,ETHEXT-6YL 1.82 m (6ft)
* 988-10113-002  Installation Manual
* 988-10122-001  Mounting Template
* 988-10118-001  Limited warranty card, SIMRAD
* Hardware Mounting Kit
* Scanstrut Mount Brochure
