Humminbird ONIX 10 CXI Combo Fish Finder with Sonar, GPS

Humminbird ONIX10 cxi SI Combo - TouchScreen, the possibility of their own mapping with the new car chart system and an excellent 2D sonar system. This system offers everything that makes the angler happy.

Technical details:

• Switch Fire Sonar
• Snapshot mode for photos screen
• Sonar Recording
• Split Screen Zoom
• Split Screen Bottom Lock
• Wide Narrow Cone Split Screen
• Live sonar imaging (important for many fishing methods!)
• Selective Fish ID +
• Real Time Sonar RTS Window
• 3D Chart View

screen:

• Multi-Touch
• 26.4 cm screen diagonal (10.4 "diagonal)
• 768V x 1024H
• Color TFT

Cartography:

• Humminbird TriFuel ™ Base Maps
• Humminbird mapping with auto chart
• Compatible Navionics Platinum + and Gold
• C-Map by Jeppesen compatible

memory:

• Waypoints: 3,000
• Routes: 200
• Tracks: 50 w/20, 000 points

Sonar:

• Digital Signal Processing (DSP) - 180 ° coverage
• HD Side Imaging / Down Imaging HD
• 455kHz (2) 86 ° @-10db
• 800kHz (2) 45 ° @-10db
• 150 ft (SI); 350 ft (DI)
• DualBeam PLUS with Fireswitch
• 200 kHz / 20 ° @-10db
• 83 kHz / 60 ° @-10db
• maximum depth of about 450m
• (1000m with optional 200/50 kHz transducer for deep water or up to 3000m with optional Ethernet CHIRP sonar)

Performance:

• 1000 Watts (RMS)
• 8000 Watts (peak-to-peak)

GPS Feature:

• Internal GPS antenna
• Trackplotting
• chartplotting
• GPS speed
• Humminbird TriFuel for different chart systems, such as Navionics and CMap charts

SYSTEM Network:

• i-Pilot ® LINK (optional)
• Ethernet Networking (optional)
• 360 Imaging (optional)
• Radar (optional)
• NMEA 2000

Scope of delivery:

• Humminbird ONIX10 cxi SI Combo including device base
• power cable
• Standard encoder: XT-14-20-T HDSDI
• Fixed installation fixing material
• English and German manual
