Suzuki Outboard Motor Mid-Range DF60A - 20 in shaft

Engineered to deliver fuel-efficient operation in a compact and light weight design, the DF60A utilizes many of the advancements that Suzuki has pioneered over the last decade. This three-cylinder engine with a four valve DOHC design is combined with Suzuki's Lean Burn Control System to deliver high-tech performance with efficient operation and top level fuel economy. New DF60A models also sport the optional Suzuki Troll Mode System.

Features:

• Multi Point Sequential Electronic Fuel Injection
• Suzuki Lean Burn Control System
• Suzuki Troll Mode System
• Direct Ignition
• Suzuki Easy Start System
• Over-Rev. Limiter
• Low Oil Pressure Caution
• Fully Transistorized Ignition
• Timing Chain
• Fresh Water Flushing System
• Power Trim and Tilt
• Tilt Limit
• Suzuki Anti-Corrosion System

Engine:

• Engine Type    3 cylinders, DOHC 12-Valve
• Bore x Stroke    2.85 x 2.99 in. (72.5 x 76 mm)
• Displacement    57.4 cu.in. (941 cc)
• Starting    Electric

Dimensions:

• Shaft Length    20 in.
• Weight    229 lb.

General:

• Trim Method    Power Trim and Tilt
• Propshaft Horsepower    60 hp
• Full Throttle Operating Range    5300 - 6300 rpm
• Gear Ratio / Shift    2.27:1
• Fuel Induction    Multi Point Sequential Electronic Fuel Injection
• Alternator    12V 19A
• Steering    Remote (Tiller Kit Optional)

Specifications:

• Recommended Transom Height (inches): L: 20
• Starting System: Electric
• Weight (lb.): L: 229
• Engine Type: DOHC 12-Valve
• Fuel Delivery System: Multi Point Sequential Electronic Fuel Injection
• Number of Cylinders: 3
• Piston Displacement inches (cc): 57.4 (941)
• Bore x Stroke inches (mm): 2.85 x 2.99 (72.5 x 76)
• Maximum Output HP: 60
• Operating Range (rpm): 5300 - 6300
• Steering: Remote (Tiller Kit Optional)
• Oil Pan Capacity quarts (liter): 2.9 (2.7)
• Ignition System: Solid State Direct Ignition
• Alternator: 12V 19A
• Trim Position: Power Trim and Tilt
• Gear Ratio: 2.27:1
• Standard Propeller: Optional See Dealer
• Propeller Selection: 9 - 17
